2-Channel RS232 Module for Raspberry Pi Pico, SP3232EEN Transceiver, UART To RS232
- Brand
- Waveshare
- SKU:
- 1886
Waveshare 19979 - 2-Channel RS232 Module For Raspberry Pi Pico, SP3232EEN Transceiver, UART To RS232 - Pico-2CH-RS232
Features
- Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series
- Using UART bus, easily converting UART to RS232, or vice versa
- Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
Specifications
Operating voltage | 3.3V-5V | RS232 transceiver | SP3232EEN |
---|---|---|---|
Communication bus | UART | Baudrate | 300~912600bps |
What's On Board
- SP3232 RS232 transceiver
- Raspberry Pi Pico header
- RS232 bus interface 2-channel RS232 (DB9 male connector is also available through adapter cable)
- VS diode
- ESD diode
- UART status indicators
RXD0/TXD0: Channel 0 RX/TX indicators
RXD1/TXD1: Channel 1 RX/TX indicators
Pinout Definition
Outline Dimensions
Includes
- Pico-2CH-RS232 x1
- DB9 to 3PIN adapter cable x1
Weight: 0.038 kg
Resources
- WIKI: Pico-2CH-RS232
* Resources for different product may vary, please check the wiki page to confirm the actually provided resources.
